Dgpi-8 S412ah-025 Electric Forklift Lithium Battery Pack
time：2025-02-27
Parameters：
Specifications Dgpi-8s412ah-025
1 Brand Assurance: optional Brand Cell
2 Long Life: battery Cycle Times> 2000
3 System Security: equipped with Smart BMS to Monitor the Battery Status in Real Time and Protect the Battery
| Model |
DGPI- 8S412Ah-025 |
| battery Specification |
8S2P/25.6V/412Ah |
| nominal Voltage |
24V |
| nominal capacity |
412Ah |
| Charging voltage | 29.2V |
| charging current |
≤ 60A |
| discharge current |
≤ 60A |
| discharge overcurrent protection Current |
70A(10s), 120A(100ms) |
| discharge cut-off voltage |
22V |
| Cell specifications | ganfeng/square 206Ah/lithium iron phosphate |
| finished product internal resistance |
≤ 20 Mohm |
| battery weight |
88Kg ± 5Kg |
| product Size |
l632mm*W400mm*H294mm(Max) |
| charging temperature protection |
0°C to 55°C |
| Discharge temperature protection | -20°C ~ 60°C |
| battery shell |
metal Shell |
| lithium battery protection |
short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, equalization, etc. |
| Communication mode |
RS485 & RS232 |
